eForce Amp+
- Shimano STEPS EP8 Drive Unit
- Shimano BT-8036 630Wh Battery
- SRAM SX Eagle Drivetrain
$3,100.00
product description
eForce Amp+
The eForce Amp+ is equipped with GT’s e-tuned LTS platform, Shimano’s STEPS EP8 Drive Unit, Shimano 630Wh Battery, 29″ wheels, 150mm of travel, and RockShox suspension, making it a powerful trail bike.
LTS Suspension
Linkage Tuned Suspension offers a steady and economical suspension foundation. The 4-bar system is intended to be a highly adjustable suspension platform that maintains ground-hugging traction even under hard braking.
Shimano STEPS equipped
Shimano’s STEPS offers riders steady power and user-friendly connectivity. Their fully integrated e-bike systems offer greater versatility and emphasize the true independence of your travels.
Frame
frame: eForce Alloy 29” Frame, 150mm Travel, Shimano STEPS, 12x148mm Thru-Axle
sizes available: SM, MD, LG, XL
fork: RockShox Yari RC, 150mm, E-MTB, Motion Control, 42mm Offset
rear shock: RockShox Deluxe Select R, 185x55mm Trunnion
wheel size: 29
Wheels
rims: WTB STX i30 TCS, 32h, Tubeless Ready
front hub: Formula, 15x110mm
rear hub: Formula, 12x148mm, HG Freehub Body
front tire: Maxxis Minion DHF, 29×2.6″, 3C MaxxTerra, EXO+
rear tire: Maxxis Minion DHR II, 29×2.6″, 3C MaxxTerra, EXO+
Drivetrain
rear derailleur: SRAM SX Eagle
shifters: SRAM SX Eagle, 12-Speed
rear cogs: SRAM PG-1210, 11-50T
chain: SRAM SX Eagle, 12-Speed
crank: FSA CK-752 EP8, 165mm, 34T
pedals: GT Slim Line Flat Pedal
Cockpit
handlebar: GT Alloy Riser Bar, 20mm Rise, 780mm, 5° Up, 8° Back
stem: GT Alloy, 35mm
grips: GT Statement Logo
headset: FSA No.42
seatpost: TranzX Dropper, 31.6mm, (S – 130mm, M – 150mm, L/XL – 170mm)
saddle: WTB Silverado Sport
Brakes
brakes: Slate T4, 203/203mm Rotors
E-Bike
drive unit: Shimano DU-EP801
battery: Shimano BT-E8036, 630Wh
display: Shimano SC-EM800
charger: Shimano EC-E6000-1
Geometry
| Sizes (mm) | SM | MD | LG | XL |
|---|---|---|---|---|
| Seat tube length | 430 | 450 | 480 | 510 |
| Seat tube angle effective | 76 ° | 76 ° | 76 ° | 76 ° |
| Top tube horizontal | 579 | 604 | 629 | 656 |
| Head tube angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Standover | 735 | 739 | 755 | 776 |
| Head tube length | 115 | 115 | 115 | 124 |
| Wheelbase | 1209 | 1234 | 1259 | 1288 |
| Front center | 756 | 781 | 806 | 835 |
| Chainstay length | 455 | 455 | 455 | 455 |
| Bottom bracket drop | 30 | 30 | 30 | 30 |
| Bottom bracket height | 349.5 | 349.5 | 349.5 | 349.5 |
| Fork rake | 51 | 51 | 51 | 51 |
| Trail | 121 | 121 | 121 | 121 |
| Stack | 617 | 617 | 617 | 626 |
| Reach | 425 | 450 | 475 | 500 |
| Travel front | 150 | 150 | 150 | 150 |
| Travel rear | 150 | 150 | 150 | 150 |
